mPC-T

Tough, transparent and heat resisitance

750 gram / spool

39.9 USD

*excl. VAT


  • mPC-T is a high mechanical strength polycarbonate based material which offers twice tensile strength and twice bending strength of regular ABS material, it offers heat resistance up to 110℃/230℉ with high transparency, in addition to high resistance to warp and cracking, you can easily print with it reassuringly.

Material features:

  • Excellent machanical strength
  • Excellent machinability, easy to drill on the prints
  • Heat resistant up to 110℃/230℉
  • Easy for mechanical polishing with abrasive paper to achieve a smooth surface
  • Easy to paint
  • Good optical clarity

Available for:

  • Mankati E180

Applications:

  • Functional parts
  • Heat resistant application
  • Transparent surface prototyping
  • Structure parts

It is recommended to close the door and cover the lid in the printing process to ensure stable chamber temperature and enhance higher layer bonding force.

Specification:

  • Recommended Extrusion/Nozzle Temperature: 240-260°C (464-500°F)
  • Recommended Build Plate Temperature: 60-90°C (140-194°F)
  • Recommended Print Speed: 40 - 120 mm/s
  • Net Weight: 750 gram/spool
  • Filament Diameter: 1.75 mm +/- 0.05 mm (+/- 0.02 mm typical)
  • Spool Diameter: 200 mm/7.87"
  • Spool Width: 53 mm/2.08"
  • Spool Hub Hole Diameter: 55 mm/2.16"

Shipping:

  • Shipping Size: L215mm × W215mm × H65mm
  • Shipping Weight: 1.2 kg

Print sample:
