ESD Safe ABS

Surface resistance, Proper impact & elongation strength

download technical data sheet


3DXTech 3DXSTAT™ ESD-SAFE ABS

10^7 to 10^9 Ohm surface resistivity on 3DP sample using concentric ring method.

DXSTAT™ ESD ABS is an advanced ESD-Safe compound designed for use in critical applications that require electrostatic discharge (ESD) protection and a high level of cleanliness.  Manufactured with consistency in mind - 3DXTech starts with MG-94 Premium ABS (same resin as P430, M30) and then compounded according to a proprietary formulation of carbon additives and process / dispersion modifiers - giving you a filament with excellent printing characteristics and consistent ESD properties.

Note:  Internal studies have indicated that increased extruder temperatures can achieve higher levels of conductivity.  Likewise, lower extruder temperatures have resulted in lower levels of conductivity. Each printer is set-up differently as well as varied part geometry.  Therefore, expect some trial time to understand how this filament works in your specific printer / application.

Material features:

  • Consistent and reliable surface resistance
  • Improved retention of impact & elongation vs. similiar ESD-safe materials
  • Low particulate contamination
  • Minimal contribution to outgassing and ionic contamination

Available for:

  • Mankati E180

Applications:

  • Semi-con:  HDD Components, Wafer Handling, Jigs, Casings, & Connectors
  • Industrial:  Conveying, Metering, and Sensing applications
  • Target conductivity for 3DXSTAT™ ESD ABS:
