Mankati E360

Big size for big ideas

With a large build volume at 360*360*300mm, the Mankati E360 is a huge 3D printer built for heavy jobs, you can always expect high quality outputs from it.

Mankati E360 3D Printer

Power Failure.png
Remind you to change the filament while it runs out, and record the position to continue printing.

Wi-Fi and Ethernet

Forget about SD card, you can now start your print job just sitting by the computer, via your local network wirelessly.

Print Resuming

Don't worry about power failure, the device record the instantaneous state when it happened, you can always resume the print job after rebooting.

Materials Detection

Once the filament runs out or is broken, the optical sensor inside the print head will detect that and pause printing immediately.


Carbon fiber.png

Carbon Fiber Build Plate

Mankati E360 uses a 3 mm carbon fiber build plate, which has an excellent rigidity, it won't be smashed to pieces. Due to its high impact strength, you can easily remove the prints in one piece by hitting the back of the plate.


Photoelectric Calibration

The photoelectric calibration function gives a quantizable method to leveling the plate, when the nozzle contact the sensor point of the plate, the LED light will shining, calibrate the four sensor point will level the plate.


Removable Plate

It is a removable build plate which can be easily taken off without any wire connections. With the StickSurf 3D printing surface, you can printing PLA, ABS, PC, TPU, PETG without using glues and tapes.


Safe and Tough


Air Filter

To bring your office in fresh air even work with the odorous materials, like ABS/HIPS, we build-in powerful air filter inside the printer chassis.


Linear Rails and Ball Screws

To ensure long term durability and precision, Mankati E360 adopts industrial-grade linear rails and ball screws.


Fully Enclosed Chassis

Mankati E360 is a fully enclosed 3D printer, the enclosed chassis ensures stable inner temperature and high printing performance, you can access the prints by open the front door and the top cover.



Powerful Control System

on board camera of Mankati E360 3D printer

Build-in Camera

Together with cluster management and Wi-Fi/ethernet, the on-board camera enabling you to remote monitor your printer and print job.


On-board Memory

8GB  memory space on board, the system will auto save the print files sent via local network, and auto delete the earliest files when the memory is full.

Hot plug.png

Unplug Disk Once Started

You don't need to keep the USB disk on printer after start printing, this make the file management much easier, to print on different Mankati printers, you just need to save files in one u-disk instead of many SD cards.


Standard equipped a PolyBox

To ensure good printing quality when using nylon and other hygroscopic materials, we standard equipped a PolyBox with E360 which gives a stable humidity space for your filaments.

In the meantime, the clean filament path makes your desk clean and clear, also quite reduce the chance of filament intertwining.


Photoelectric calibration

When the nozzle contact with the plate, the LED light on the inner edge of the plate will flicker. The calibration method is easy and accurate.


Easy to access print head

You can easily maintain the print head without dealing with many screws and wires.

Software

Wireless Control, Print and Monitor

With mRemote, you can achieve the basic operation of Mankati E series 3D printer and monitor the whole printing process just sitting by your computer. No need to shuttle between your printer and computer.

Cluster Management

It is a good news for the printing service providers, or the users who has multi Mankati E series 3D printers in hand. With mRemote, you can manage all your Mankati 3D printers and multi-task simultaneously, which will help you to improve your production efficiency extremely.

Specifications


Mankati E360

Technology:  MPM (Melted Plastic Modeling)

Build Volume: 360 × 360 × 300 mm (14.17 × 14.17 × 11.8 in)

Layer Height: 0.06-0.26 mm (0.002-0.01 in)



Build Plate

Build Surface: Carbon Fiber Plate

Build Plate Maximum Temperature: 110 ℃ (230 ℉)

Removable Surface: Yes



mExtruder

Nozzle Diameter: 0.3, 0.4, 0.5, 0.6 mm

Extruder Maximum Temperature: 350 ℃ (662℉)

Materials Detection: Automatically pause printing when run out of material

Cooling: Two direction air blowing printing area

Extruder Structure: full metal extruder for easy maintenance and repair



Software

Operating System: Windows 7/8/10

File Format: STL, OBJ, mcode, gcode

Slice and Print Software: Mankati mWare

Cluster Manage Software: Mankati mRemote

Software Language: English, Chinese



Hardware

Main Control Processor: STM32 ARM 32bits Chip

Embedded Processor: Dual Core 1.2 GHz ARM Cortex Chip

On-board Storage: 4 GB

Positioning Precision (X/Y): 1.5 Microns

Positioning Precision (Z): 1 Micron

Interface: Wi-Fi, Ethernet, U-Disk

Air Purification: Yes

On-boarad Camera: Yes



Material

Available Materials: mNylon 66, mNylon 6, mPP-GF, mABS, mPC, mPLA, etc.

Material Diameter: 1.75mm(0.096in)

Package

Device Dimensions (Without Spool Holder): 545 × 540 × 650 mm ( 21.45 ×  21.26 × 25.6 in )

Device Net Weight: 68 kg (150 lb)

Package Dimensions: 626 x 656 x 940 mm ( 24.64 × 25.8  × 37 in )

Package Weight: 81 kg (178.5 lb)
